Dej thoob Mould

Cov hauv qab no yog cov ntsiab lus luv luv ntawm kev tsim thiab ua cov txheej txheem ntawm tsev neeg cov yas haus dej thoob pwm thiab lub hau pwm,

Nws tsuas yog siv 3D software rau kev tsim, qauv khoom hauv 3D, thiab tshuaj xyuas cov qauv. Cov qauv no muaj xws li ib tug slider, ib tug inclined sab saum toj thaiv, thiab ib tug demoulding. Cov khoom yas yog lub plhaub, thiab cov txheej txheem tsim ntawm cov txheej txheem pouring siv ntau lub chamber sab qhov rooj los tsim thiab ua cov kev suav tsim nyog thiab cov qauv tsim rau cov khoom molded. Thaum kawg, Autocad ua tiav qhov tsim ntawm machining engineering kos duab thiab txiav txim siab ntau yam hauv kev tsim.
1. Thaum tso qhov kev txiav txim, tsim ib daim duab 3D raws li tus neeg siv khoom 2D daim duab lossis qauv rau kev pom zoo.
2. High tech: Advanced ob-theem taper positioning thev naus laus zis thiab zawv zawg ywj pheej ntawm tus kheej-locking kom ntseeg tau qhov sib txawv ntawm cov khoom.
3. Independent kub tswj cua sov system, uniform cua sov kub

Peb paub tias txhawm rau ua kom luv luv lub voj voog ntau lawm, peb feem ntau xaiv siv beryllium bronze kom luv lub sij hawm txias hauv cov txheej txheem yas yas pwm, tab sis beryllium bronze kuj muaj ntau yam zoo.
Ua ntej,beryllium bronze muaj qhov hnav tsis kam thiab corrosion kuj, uas tuaj yeem tiv thaiv cov pwm ntawm kev puas tsuaj. Qhov no ua rau beryllium bronze yog ib qho ntawm cov khoom siv pwm feem ntau siv hauv cov khoom siv yas.
Thib ob,beryllium bronze muaj cov thermal conductivity zoo, uas tuaj yeem faib qhov kub ntawm pwm, yog li ua kom muaj kev ruaj ntseg zoo thiab sib xws ntawm cov khoom yas. Qhov no yog qhov tseem ceeb tshwj xeeb rau kev tsim cov khoom siv yas siab.
Ntxiv rau,beryllium bronze kuj muaj lub zog siab thiab hardness, uas tuaj yeem tiv taus qee qhov kev cuam tshuam thiab kev cuam tshuam, yog li ua rau lub neej ua haujlwm ntawm pwm.
Thaum kawg,beryllium bronze kuj yog ib qho yooj yim rau txheej txheem rau ntau yam duab ntawm pwm, thiab tus nqi kuj tsawg. Qhov no ua rau beryllium bronze dav siv hauv kev tsim cov khoom yas.
Hauv cov ntsiab lus,beryllium bronze, raws li cov khoom pwm zoo heev, ua lub luag haujlwm tseem ceeb hauv kev tsim cov khoom yas, nrog kev hnav zoo, kev tiv thaiv corrosion, thermal conductivity, thiab siab zog. Peb yuav tsum nquag tshawb nrhiav nws lub peev xwm thiab ua kom muaj txiaj ntsig ntau dua rau kev txhim kho kev lag luam yas.

1. Cov neeg siv khoom muab 1 qauv lossis 2D / 3D kos duab
2. Ob sab thiab peb-dimensional khoom daim duab
3. CAD Pwm Tsim
4. Xa cov duab kos rau cov neeg siv khoom kom paub meej
5. Kev tshuaj xyuas qhov chaw / CNC machining / EDN machining
6. Pwm sib dhos
7. Pwm Test
8. Xa cov qauv kom paub meej
9. Kev xa cov pwm

Cov kauj ruam kawg thiab tseem ceeb heev yog cov txheej txheem ua thiab ntim cov txheej txheem ua ntej cov dej yas thoob pwm xa tuaj. Thiab qee qhov tsis yooj yim pwm accessories khoom plig rau cov neeg siv khoom.
1. Qhov saum npoo ntawm lub thoob dej pwm core thiab kab noj hniav yuav coated nrog cov xim pleev xim.
2. Qhov saum npoo ntawm pwm yuav npog nrog butter
3. Cov pwm yuav ntim nrog cov yas zaj duab xis.
4. Cov pwm yuav muab tso rau hauv ib lub thawv ntoo.
5. Npaj ib co lwm yam khoom seem thiab tag nrho cov ntaub ntawv (2D / 3D kos duab thiab kho cov duab kos), nrog rau qee qhov chaw tsis zoo xws li cov springs, sab saum toj rods, txias connectors, thiab qhov ncauj qhov ntswg. Ntim nrog pwm
Peb yuav npaj qee qhov chaw tsis muaj zog, xws li cov kab nrib pleb, cov pins sab saum toj, cov khoom sib txuas ua kom txias, thiab lub qhov ncauj qhov ntswg. Ntim nrog pwm

Pwm Hlau

Kub khiav System

Standard Parts

Txhawm rau kom ua tiav kev ua tiav ntawm txhua qhov haujlwm, Aoxu Mould tau tsim kom muaj kev tswj hwm zoo ntawm pwm. Peb pab neeg tswj xyuas kev ua tau zoo yuav ua txhua yam rau hauv daim ntawv ntawm "kev npaj + kev saib xyuas + kev tiv thaiv + kev sib kis". Cov txheej txheem hauv qab no kuj tseem siv tau rau tsev neeg cov yas haus dej thoob pwm
1. Pwm tsim tswj
Kelon tuaj yeem muab cov khoom soj ntsuam thiab cov txheej txheem pwm, thiab muab cov lus qhia rau cov neeg siv khoom ntawm cov teeb meem uas tshwm sim ntawm cov khoom kos duab, xws li nyias thickness, shrinkage marks, welding marks, ventilation opens, undercutting, rooj vag txoj hauj lwm, rooj vag hom, thiab lwm yam. tsim kom tiav, peb yuav tshuaj xyuas cov pwm lub zog, ib feem kab, cua txias system, cuam tshuam cov cheeb tsam, nyias thickness, thiab lwm yam. Kom paub meej tias cov kos duab muab los ntawm Kelon yog nyob rau hauv zoo, thiab muab cov neeg muas zaub nrog ntev pwm lub neej thiab ua hauj lwm efficiency. .
2. Pwm khoom tswj
Cov neeg muab khoom hlau yuav tsum tau muab daim ntawv pov thawj steel zoo thiab daim ntawv pov thawj steel tsim nyog, thiab Kelon yuav ua cov tshuaj ntsuam xyuas steel ua ntej txais.
3. Kev tswj zoo ntawm kev ua pwm
Raws li cov ntaub ntawv ua pwm, peb tswj xyuas qhov zoo ntawm cov txheej txheem tseem ceeb thiab tswj xyuas qhov project. Peb muab cov ntaub ntawv ua tau zoo txhua lub lim tiam thiab cov ntaub ntawv zoo rau peb cov neeg siv khoom.
Cov kws tshaj lij pwm yuav tsum ua tib zoo tshuaj xyuas qhov zoo li, qhov system txias, pwm sib dhos, thiab cov txheej txheem ntawm pwm raws li Kelon cov qauv thiab cov neeg siv khoom.
4. Kev yuav khoom thiab tswj cov pwm Spare xeem
Peb yuav tsom mus rau qhov tsim nyog cov khoom seem kom tau raws li cov neeg siv khoom xav tau rau cov qauv qauv, qauv zoo, thiab lub sijhawm yuav khoom.
5. Pwm sib dhos tswj
Kev ua lub cev yuav raug ua raws li cov ntaub ntawv tsim tawm, thiab kev tshuaj xyuas cov txheeb ze yuav tsum ua nruj me ntsis xyuas qhov sib txuam ntawm cov tub ntxhais, kab noj hniav, ntxig, qhia ncej, rov qab tus pin, lub kaum sab xis lifter, slider, sab saum toj pas nrig, cua txias system, connector, lwm.
6. Tshawb xyuas cov pwm ua ntej ua zaub mov xa tuaj
Npaj cov ntaub ntawv ua ntej ua zaub mov xa tuaj, xws li cov npe khoom seem, pwm kuaj video, ua cov ntaub ntawv, 2D / 3D kos duab. Tau kawg, peb yuav ntim thiab thauj raws li cov neeg siv khoom xav tau, thiab muab kev tiv thaiv kev nyab xeeb rau kev thauj mus los hauv hiav txwv thiab huab cua.
