Yas Cia Pob Tawb Mould



Pwm npe	Yas Cia Pob Tawb Mould
Khoom Siv Khoom	Pp, yas
Cov khoom loj	450 x 400x420mm
Khoom yuag	1.5kg
Pwm khoom rau kab noj hniav &. Lub hlwb	P20, 718, 2738
Nos ntawm kab noj hniav	1 kab noj hniav
Kev Txhaj Tshuaj System	Kub Khiav 4 taw tes Kates
Kev txhaj tshuaj tshuab	650T
Tuaj pwm loj	850x800x 860 hli
Pwm Lub Neej	Ntau tshaj 500, 000 pcs





1. Khoom npaj npaj

>Cov hnab yas ntxiv xaiv: Cov ntaub ntawv nquag muaj xws li PP (polypeylene), HDPropylene), HDPE-ntom polyethylene), lossis tsis muaj zog raws lub zog, thiab tus nqi yuav tsum tau ua.

>Kom qhuav (yog xav tau): ib yam yas (zoo li abs) yuav tsum tau qhuav kom tshem tawm noo noo ua ntej molding.

>Xim sib xyaw (yeem): masterbatch lossis kua dyes tuaj yeem ntxiv rau cov pob tawb xim.

2. Txhaj Tshuaj Moulding Tshuab Teeb

>Clamping chav tsev: Tuav cov pwm ruaj khov nyob rau hauv kev kub siab.

>Txhaj chav nqus: melts thiab txhaj yas rau hauv pwm.

>Pwm Installation: Lub pob tawb ntim khoom (ua los ntawm cov hlau) yog mounted mus rau lub tshuab.

3. Kev txhaj tshuaj moulding txheej txheem kauj ruam-los-kauj ruam

Kauj ruam 1: Pwm Kaw

Qhov ob halves ntawm cov pwm (Core & kab noj hniav) yog clamped ua ke nyob rau hauv kev kub siab (feem ntau 50-500 tons, nyob ntawm pob tawb loj).

Kauj ruam 2: Yas melting & Txhaj

Cov pellets yas pub rau hauv lub thoob khib nyiab (180-280 degree, nyob ntawm cov khoom).

Cov ntsia hlau recrocating thawb molten yas rau hauv cov pwm kab noj hniav ntawm kev kub siab (500-1,500 bar).

Kauj ruam 3: Cua txias & solidification

Cov yas txias sab hauv cov pwm (lub sijhawm txias txawv ntawm 10-60 vib nas this).

Cua txias raws nyob rau hauv cov pwm pab kom cov txheej txheem ceev ceev.

Kauj ruam 4: Pwm Qhib & Ejection

Cov pwm qhib, thiab ejector Pins thawb lub pob tawb tawm.

Rau cov qauv tsim qauv (zoo li Stockable pob tawb), cov phiaj sawb, cov phiaj hlau tuaj yeem pab ection.

Kauj Ruam 5: Kev Xa Khoom Tom Qab (Yog xav tau)

TRIMMING: Ntau dhau Yas (Nyem) raug tshem tawm.

Nto kho: texturing, luam ntawv, lossis sib dhos (yog tias lub pob tawb muaj nyias nyias).





Txawm hais tias ib lub pob tawb ntim khoom siv tau cov tshuab khiav kub yog nyob ntawm ob peb qhov tseem ceeb. Ntawm no yog cov kev txheeb xyuas kev tshaj lij:

Cov Lus Taw Qhia:

Rau feem ntau cia pob tawb ntau lawm, txias khiav tshuab feem ntau yog txaus thiab muaj txiaj ntsig zoo. Cov neeg khiav kub feem ntau tsuas yog tsuas yog muaj tseeb rau:

1. HEEV HIGH-VOLDING NTAU LAWM (100, 000+ units)

2. Cov xov xwm zoo uas xav tau lub rooj sib nraus zoo nkauj

3. Ntau-kab noj hniav pwm (4+ cov kab ke) uas cov khoom txuag tau ua qhov tseem ceeb

Kev txiav txim siab txog kev:

1. Cov neeg ua yeeb yam kub tshem tawm cov khib nyiab khiav ceev, tab sis cov pob tawb cia siv tas li (PP \/ HDPE) qhov twg cov khoom siv nyiaj yuav tsis pom zoo txog tus nqi ntxiv.

2. Qhov txiaj ntsig zoo: Thaum cov neeg khiav kub muab lub rooj vag zoo dua qub, khoom cia yog cov khoom lag luam me nyuam yaus feem ntau tau txais.

3. Mould nyuaj: Cia Pob Tawb Pwm yog feem ntau loj tab sis kuj yooj yim - txias khiav tau yooj yim los tswj thiab kho.

4. Ntau lawm nplai: Qhov tawg-txawm taw tes rau cov kev khiav tawm kub feem ntau tshwm sim nyob ib ncig ntawm 500, {} cms - ntsuas koj cov ntim khoom lag luam zoo.

Rau feem ntau cov chaw tsim khoom, ib tus qauv txias khiav system nrog kev ua kom zoo (nyiam qhov sib npaug zoo tshaj plaws ntawm cov nqi thiab kev ua tau zoo rau cov thawv ntim khoom lag luam. Cov neeg khiav kub tsuas yog txiav txim siab thaum cov ntim khoom siv tau qhia meej meej rau cov khoom siv ntxiv rau ntxiv.









1. Txhais tau pob tawb & lub hau yuav tsum tau

>Ua ntej tsim qauv pwm, ua tiav cov khoom lag luam:

>Qhov loj me (ntev × × × qhov siab, suav nrog lub hau)

>Phab Ntsa Thickness (feem ntau 2-3mm rau lub zog thiab qhov hnyav sib npaug)

>Cov khoom siv (PP, HDPE, lossis ABS rau kev yoog thiab cuam tshuam)

>Load muaj peev xwm (txiav txim siab Tynage reaging xav tau)

>LID Snordment Street (pob taws, snap-haum, lossis cais)

2. Cov Txheej Txheem Kev Tsim Kho

A. Pob tawb Lub Cev Tsim

>Puag & Soj ntsuam:

Ntxiv cov tav rau qhov cuab lub zog (yog tias cov khoom siv hnyav yuav tsum tau).

Suav nrog cov ntawv sau cov ces kaum (1-2 degree) rau kev ejection yooj yim los ntawm cov pwm.

Qhov cua tshuab (yog tias xav tau rau airflow) yuav tsum muaj tusyees spaced.

>Stackability feature: tsim kev sib cav sib ceg saum toj \/ hauv qab rau stabing stacking.

>Tuam tsev: Cov Khoom Siv Hauv Compedles (moulded ua ib feem ntawm lub pob tawb) lossis txiav-tawm grips.

B. Lid Design

>Pob khawm thiab lub hau-ntawm lub hau: Pob taws (nyob khawm): yuav tsum muaj ntu nyias, feem ntau yog PP).

>Snap-haum Ntse: Xav tau cov kev ua kom zoo thiab thev taus rau kev nyab xeeb.

>Ntsia qhov cuab kav:

Ntxiv cov tav los tiv thaiv kev ua rog.

Nco ntsoov tias Tiaj xim sealing nto yog tias xav tau airtight cia.

>Kov lossis Grips: ib tug pwm kov lossis ntiv tes zuaj rau yooj yim qhib.

3. Pwm Tsim Kev Txiav Txim Siab

A. Parting Line & Core \/ kab noj hniav

Cov kab ntu yuav tsum txo qis cov nqaws pom (feem ntau nrog cov pob tawb rau sab saum toj ntug).

Tub ntxhais & kab noj hniav ntxig yuav tsum muaj kev sib daj kom tsis txhob nyem (ntau dhau cov yas).

B. Ejection System

Ejector pins yuav tsum thawb lub pob tawb uas tsis muaj cim rau ntawm cov chaw pom.

Rau cov pob tawb sib sib zog nqus, cov phiaj hlua khau hlau yuav tsum muaj kev xav kom zoo.

C. Undercuts (rau Snap-Haum Hau)

Sab kev (cov kab yub) lossis cores collesible yuav tsum muaj rau cov nta SNAPT.

Yog tias siv lub pob khawm nyob, xyuas kom kom muaj cua txias kom tsis txhob muaj cov pob hluav taws xob tsis muaj zog.

D. Kev kaw lus txias

Uafmal txias channels pab txo cov voj voog thiab warping.

Qhov tseem ceeb rau kev ua haujlwm txias, tshwj xeeb yog ib ncig ntawm cov kab tuab tuab (khi, tav).

E. VOJ

Kev cog kom yog tiv thaiv huab cua (hlawv cov cim) hauv kev sib sib zog nqus





Pwm hlau

KUB khiav system



Txheem Qhov







>1. Koj tuaj yeem kho qhov loj me thiab cov duab ntawm cov pob tawb cia kom pwm raws li peb cov kev xav tau?

Yog lawm, peb tuaj yeem kho qhov loj me, cov qauv, thiab tsim cov pob tawb cia kom haum rau koj cov kev xav tau tshwj xeeb.

>2. Cov ntaub ntawv twg koj siv los tsim cov pob tawb ntim khoom tuaj pwm?

Pwm Cuag: Hardened Hlau (P20, 718, H13)

Yas Cov Khoom Siv Khoom Siv Yas: PP, HDPE, ABS, lossis PS (nyob ntawm pob tawb uas yuav tsum tau).

>3. Ntev npaum li cas nws siv sijhawm los tsim cov pob tawb cia pwm?

Lub sijhawm tsim khoom rau lub pob tawb ntim khoom tuaj yeem sib txawv nyob ntawm qhov nyuaj thiab qhov loj me ntawm cov pwm. Feem ntau nws yuav noj 45-55 hnub. Txawm li cas los xij, peb siv zog kom xa cov pwm ua kom raws sijhawm.

>4. Koj puas muab cov qauv ua haujlwm ua ntej pawg ntau lawm?

Yog lawm, peb muab cov qauv T1 (thawj qhov chaw sib txheeb) kom pom zoo ua ntej tag nrho cov khoom lag luam.

Q: Koj puas muab kev txhawb nqa tom qab muag rau lub pob tawb ntim khoom?

>5. Cov ntsiab lus them nqi li cas?

TT, 40% tso nyiaj, 30% yuav tsum tau them ua ntej xa cov qauv, 30% tshuav nyiaj li cas ua ntej xa khoom tuaj pwm.

>6. Koj puas muab kev muag khoom tom qab muag rau lub pob tawb ntim khoom?

Yog lawm, peb muab cov teeb meem tom qab los daws cov teeb meem lossis kev txhawj xeeb koj yuav muaj nrog cov pob tawb ntim khoom.

>7. Koj puas tuaj yeem pab nrog kev teeb tsa thiab kev saib xyuas ntawm cov pob tawb ntim khoom tuaj?

A: Yog lawm, peb tuaj yeem muab kev pab nrog lub installation thiab saib xyuas ntawm lub pob tawb khaws cia pwm kom ntseeg tau tias kev ua tau zoo tshaj plaws.

>8. Koj ua li cas kom cov pwm ua tau zoo?

Precision Machining (CNC, EDM, sib tsoo)

Kev Ntsuam Xyuas pwm (txhawm rau tiv thaiv tsis xws luag zoo li warping \/ dab dej)

Kev Soj Ntsuam Zoo (Kev Ntsuam Xyuas Sab Hauv, Kev Sim Ua)
